Product Overview
The ABB DSQC627 3HAC020466-001 is a high-performance 16-Channel Digital Input Module designed specifically for the ABB IRC5 robot controller system. This module serves as a critical sensory interface, enabling the robot system to reliably read the status of a wide array of digital field devices such as proximity sensors, photoelectric eyes, limit switches, and push buttons. It provides the essential link between the physical state of the robotic workcell and the robot’s control logic, allowing for adaptive and safe operation based on real-time external conditions.
As part of the DSQC I/O family, this module is engineered for industrial durability, featuring configurable input types to accommodate both sinking (NPN) and sourcing (PNP) sensor technologies. The 3HAC020466-001 variant includes specific firmware and hardware revisions optimized for compatibility and performance within modern IRC5 cabinets.
Parameter Values
-
- Product Model:DSQC627 3HAC020466-001
- Brand: ABB
- Warranty: One Year
- I/O Type: 16 Digital Inputs
- Input Voltage Range: 24 VDC (10-30 VDC)
- Input Type: Configurable as Sinking (NPN) or Sourcing (PNP)
- “ON” State Current: Typically 3-5 mA
- “ON” State Voltage Level: ≥ 15 VDC
- “OFF” State Voltage Level: ≤ 5 VDC
- Response Time: < 2 ms
- Input Filtering: Configurable via software
- Isolation Voltage: 500 VAC (channel to channel and channel to bus)
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -25°C to +85°C
- Connection: Removable screw terminal block
- Diagnostic Indicators: Green LED per channel for signal status
Application Scenarios
Machine Tending & Loading: Reading part-presence sensors in CNC machine chucks, confirming fixture clamp status, and receiving cycle-complete signals from presses or molding machines.
Packaging & Palletizing: Monitoring photo-eye sensors on infeed/outfeed conveyors, receiving signals from barcode scanners for product identification, and confirming pallet presence at the workstation.
Safety & Cell Interlocking: Interfacing with safety door switches, light curtain OSSD outputs, and area scanner zones to integrate the robot’s operational modes with the overall cell safety system.
