Description
Product Overview
The ABB TU847 3BSE022462R1 is a high-performance communication module designed for the AC 800M controller series, functioning as a dedicated PROFIBUS DP interface. This module enables the AC 800M controller to act as a PROFIBUS DP-V1 Master, allowing for the deterministic and high-speed integration of a wide range of field devices such as remote I/O, variable frequency drives, and analytical instruments into the System 800xA architecture. The ABB TU847 3BSE022462R1 handles both cyclic process data exchange and acyclic services for advanced diagnostics and parameterization. Engineered for industrial reliability, it provides electrical isolation and comprehensive diagnostics to ensure network integrity. This module is a critical component for extending the reach of the ABB control system into areas dominated by PROFIBUS technology, facilitating seamless, multi-vendor automation in complex process and manufacturing environments.
Parameter Values
- Product Model: ABB TU847 3BSE022462R1
- Brand: ABB
- Warranty: One Year
- Supply Voltage: 24 V DC
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: -40 °C to +85 °C
- Fieldbus Interface: PROFIBUS DP (RS-485), Sub-D9 connector
- PROFIBUS Standard: EN 50170, DP-V1
- Data Rate: 9.6 kbps to 12 Mbps (auto-detect)
- Function: DP-V1 Master (Class 1)
- Max. Number of Slaves: 125
- Max. I/O Data: 244 bytes input / 244 bytes output (cyclic)
- Configuration: Via Control Builder M and PROFIBUS DP Master Configurator (GSD files)
- Isolation: 500 V AC (PROFIBUS network to controller)
- Power Consumption: 3.0 W
- LED Indicators: MOD (Module Status), RUN, BUSF (Bus Fault), PORT (Tx/Rx)
- Supported Controllers: AC 800M (e.g., PM864, PM865)
- Dimensions: Standard AC 800M module size
Application Scenarios
- Process Plant Fieldbus Integration: TU847 3BSE022462R1 Connecting distributed field instruments, valve actuators, and motor starters via a PROFIBUS DP network in chemical, water treatment, or pharmaceutical plants.
- Manufacturing Automation: Controlling production lines with PROFIBUS-connected remote I/O, drives, and sensors in automotive or food & beverage manufacturing.
- Packaged Equipment Interfacing: Integrating skid-mounted systems (e.g., compressor or filtration packages) that use PROFIBUS DP as their primary communication interface into the main DCS for supervision and control.
