TK850V007 | 0 °C to +60 °C | specialized firmware variant

Description

Product Overview

The ABB TK850V007 is a specialized firmware variant of the high-performance ABB TK850 multi-protocol fieldbus communication module for the AC 800M controller platform. This specific version is engineered with optimized firmware to provide robust, deterministic connectivity, primarily excelling in PROFIBUS DP-V1 networks while retaining the module’s core capability to handle DeviceNet and CANopen protocols. The ABB TK850V007 enables the AC 800M controller to act as a PROFIBUS DP Master, integrating a vast array of field devices such as remote I/O, drives, and analyzers from numerous vendors into the ABB System 800xA. Its advanced features, including support for acyclic data exchange (for parameterization and diagnostics) and integrated diagnostics, make it a critical component for building flexible, multi-vendor automation architectures in demanding industrial environments where reliability and data integrity are paramount.

Parameter Values

• Product Model: ABB TK850V007
• Brand: ABB
• Warranty: One Year
• Supply Voltage: 24 V DC (via AC 800M backplane)
• Operating Temperature: 0 °C to +60 °C
• Storage Temperature: -40 °C to +85 °C
• Primary Fieldbus Interface: PROFIBUS DP (RS-485, Sub-D9 connector)
• PROFIBUS DP Data Rate: 9.6 kbps to 12 Mbps (auto-detect/configurable)
• PROFIBUS DP Functionality: DP-V1 Master, supporting MS0, MS1, and MS2 services
• Additional Interfaces: DeviceNet, CANopen (functional based on configuration)
• Max. Number of DP Slaves: 125
• Max. I/O Data per Network: Up to 244 bytes input / 244 bytes output (cyclic)
• Configuration: Via Control Builder M and the PROFIBUS DP Master Configurator (GSD files)
• Isolation: 500 V AC (fieldbus side to system)
• Power Consumption: 3.5 W (typical)
• LED Indicators: Module status, PROFIBUS network status (RUN/BUSF), port activity
• Dimensions: Standard AC 800M module size

Application Scenarios

• Distributed Process I/O: TK850V007  Connecting large numbers of remote I/O stations and intelligent field instruments across a plant-wide PROFIBUS DP network in chemical or pharmaceutical facilities.
• Drive & Motor Control Integration: Centralized control and monitoring of variable frequency drives and motor starters in manufacturing lines, conveyor systems, or water pumping stations via PROFIBUS.
• Packaged Skid Interfacing: Integrating factory-assembled equipment skids (e.g., compressor or filtration units) that utilize a PROFIBUS DP interface as their primary communication link to the main DCS.
