Yaskawa SGMCS-14C3C-YA12|AC Servo Motor with High Precision Control

Description

1. Product Title

Yaskawa SGMCS-14C3C-YA12 – AC Servo Motor with High Precision Control

2. Product Overview

The Yaskawa SGMCS-14C3C-YA12 is a high-performance AC servo motor, engineered for precision control and efficiency in demanding industrial applications. Known for its exceptional speed control, smooth operation, and durability, this servo motor is a key component in applications that require high torque and fast response times, such as CNC machines, robotics, material handling, and packaging equipment. The SGMCS-14C3C-YA12 integrates seamlessly with Yaskawa’s advanced drive systems, providing enhanced system performance, precise position control, and reduced operational costs.

Designed to operate under varying load conditions, the Yaskawa SGMCS-14C3C-YA12 features advanced feedback systems that ensure continuous accuracy and reliability, even in complex production environments. This motor is ideal for industries that require both high performance and energy efficiency in their automation processes.

3. Technical Specifications

• Brand: Yaskawa
• Model: Yaskawa SGMCS-14C3C-YA12
• Warranty: One Year
• Condition: 100% New & Original

Key Parameters:

• Rated Output Power: 1.0 kW
• Rated Torque: 3.18 Nm
• Rated Speed: 3000 RPM
• Feedback Type: High-resolution encoder for precise position and speed control
• Voltage Rating: 200V AC
• Current Rating: 5.4 A (at rated conditions)
• Insulation Class: Class B
• Protection Rating: IP65, ensuring protection from dust and water ingress
• Operating Temp:
  • Typically ranges from -10°C to +40°C, suitable for a wide variety of industrial settings
• Dimensions/Weight:
  • Dimensions: 146 mm (Diameter) x 179 mm (Length)
  • Weight: Approximately 6.3 kg
• Shaft Type:
  • Keyed shaft, ideal for direct coupling to machinery and equipment
• Compliance & Certifications:
  • CE, UL, and other relevant industry certifications ensuring adherence to international standards

4. Key Features & Benefits

• High Precision Control:
  The Yaskawa SGMCS-14C3C-YA12 comes with a high-resolution encoder that enables highly accurate position, speed, and torque control, ensuring precise operation in motion control applications.
• Enhanced Durability:
  With its IP65 protection rating, the motor is highly resistant to dust and water, making it suitable for challenging environments, ensuring long-lasting performance even in harsh conditions.
• Energy Efficiency:
  The advanced design of the SGMCS-14C3C-YA12 ensures efficient energy use, which helps to lower operating costs and reduce energy consumption while maintaining high performance.
• Wide Application Range:
  With its versatile design and high torque, the Yaskawa SGMCS-14C3C-YA12 is ideal for a range of industrial applications, from automated assembly lines to robotic arms, providing reliability and speed in critical processes.
• Quick Response Times:
  The servo motor provides quick acceleration and deceleration times, making it perfect for dynamic applications that require fast cycle times and high throughput.

5. Application Scenarios

• Robotics:
  In robotic systems, the Yaskawa SGMCS-14C3C-YA12 ensures precise motion control for robotic arms, enhancing accuracy in tasks such as pick-and-place, assembly, and welding.
• CNC Machinery:
  In CNC machines, this motor delivers the precise, high-torque motion required for accurate cutting, milling, and drilling, ensuring superior quality and precision in manufacturing operations.
• Material Handling:
  The SGMCS-14C3C-YA12 is ideal for material handling systems, providing smooth and reliable motion control for conveyors, automated guided vehicles (AGVs), and sorting equipment.

6. Frequently Asked Questions (FAQ)

• Q: What is the primary function of the Yaskawa SGMCS-14C3C-YA12?
  • A: The Yaskawa SGMCS-14C3C-YA12 is an AC servo motor designed for high precision control in industrial automation applications, offering precise position, speed, and torque control for systems such as robotics, CNC machinery, and material handling.
• Q: Is the Yaskawa SGMCS-14C3C-YA12 compatible with other Yaskawa drive systems?
  • A: Yes, the SGMCS-14C3C-YA12 is fully compatible with Yaskawa’s drive systems, enabling seamless integration for enhanced system performance and precise control.
