Description
Product Overview
The ABB UAD206A101 3BHE019958R0101 is a high-precision analog input module developed for ABB’s S800 I/O system and compatible with the AC 800M controller family. Tailored for process automation environments that demand high signal integrity and system reliability, this module facilitates accurate measurement of analog field signals across a broad spectrum of industrial applications. The ABB UAD206A101 3BHE019958R0101 integrates seamlessly into distributed control architectures, offering robust channel isolation, advanced diagnostics, and HART protocol support. Its design prioritizes modularity, scalability, and minimal downtime during maintenance. Ideal for critical control processes, the ABB UAD206A101 3BHE019958R0101 ensures responsive and interference-free data acquisition essential for optimized plant operation and safety compliance.
-
Product Model: ABB UAD206A101 3BHE019958R0101
-
Brand: ABB
-
Warranty: One Year
-
Input Voltage: 20 to 30 V DC ±10%
-
Operating Temperature: -25°C to +65°C
-
Storage Temperature: -40°C to +85°C
-
Response Time: ≤ 7 ms
-
Protection Class: IP20
-
Accuracy Class: ±0.06% of full scale
-
Output Frequency: N/A (Analog Input Module)
-
Rated Current Range: 0 to 20 mA / 4 to 20 mA software-selectable
-
Communication Interface: S800 High-Speed I/O Link
-
Supported Protocols: ABB I/O Link, HART pass-through
-
Overload Capacity: 110% rated input for 30 seconds
-
Dimensions: 128 mm x 82 mm x 112 mm
Key Functions
-
Universal Analog Input: Supports a variety of signal types including voltage (±10V, 0–10V), current (0–20 mA, 4–20 mA), and resistance temperature detectors (RTDs), ensuring compatibility with most industrial sensors.
-
Per-Channel Isolation: Incorporates galvanic isolation per input channel to prevent ground loop interference and enhance signal accuracy in multi-channel setups.
-
Application Scenarios
-
Chemical Processing: Interfaces with analytical probes and reactor sensors to monitor reaction parameters such as temperature, pressure, and concentration with high resolution.
-
Electric Utilities: Used in turbine control systems and flue gas monitoring stations to acquire critical analog data from substations and environmental units.
-
