Description
Product Overview
The ABB TU515 is a multi-functional communications processor module designed for the ABB AC 800M controller family. This versatile module acts as a central hub, significantly expanding the controller’s connectivity by providing multiple independent serial communication ports. It enables the AC 800M to interface directly with a wide variety of field devices, subsystems, and third-party equipment using standard protocols like Modbus RTU/ASCII. The ABB TU515 is engineered for reliability, featuring galvanic isolation on its serial ports to protect the controller from electrical noise and ground loops. It facilitates critical tasks such as data acquisition from remote sensors, supervisory control of drives, and integration of legacy systems, making it an essential component for building comprehensive, multi-vendor automation networks within the System 800xA architecture where flexible and reliable serial communication is required.
Parameter Values
- Product Model: ABB TU515
- Brand: ABB
- Warranty: One Year
- Supply Voltage: 24 V DC (via AC 800M backplane)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: -40 °C to +85 °C
- Communication Ports: 4 independent serial ports, configurable as RS-232, RS-422, or RS-485 (2- or 4-wire)
- Isolation: 500 V AC (each port to backplane)
- Data Rate: 300 bps to 115.2 kbps per port
- Supported Protocols: Modbus RTU Master/Slave, Modbus ASCII, DF1, DH485, and user-defined character-based protocols
- Configuration: Via Control Builder M engineering software
- Power Consumption: 3.0 W (typical)
- LED Indicators: Per port: Tx, Rx, RTS (if applicable), Error
- Connector: Removable screw-terminal blocks
- Simultaneous Connections: Supports multiple masters/slaves across its ports
- Dimensions: Standard AC 800M module size
Application Scenarios
- Drive & Motor Control Networks: TU515 Centralized control and monitoring of multiple variable frequency drives via Modbus RTU in a pumping station or conveyor system.
- Weighing & Batching Systems: Interfacing with multiple load cells, batch controllers, and ingredient feeders in food & beverage or pharmaceutical production.
- Plant-Wide Data Acquisition: Polling data from various stand-alone subsystems (e.g., packaged compressors, HVAC, water treatment) for centralized monitoring, data logging, and alarm management in a SCADA system.
