DO610 3BHT300009R1 | I-O_Module | DO620 Digital Output 32Ch 60VDC Isolated,4 groups

Description

Product Overview

The ABB DO610 3BHT300009R1 is a high-density digital output module designed for the ABB S600 I/O family, integral to the legacy Advant and MOD 300 distributed control systems. This module provides 32 independent output channels for reliable switching of standard 24 VDC field devices such as solenoid valves, relays, indicators, and small contactors. Engineered for robust performance in industrial environments, the ABB DO610 3BHT300009R1 features per-channel short-circuit protection and is organized into isolated groups to enhance system safety and fault tolerance. Its high channel count maximizes I/O density within the S600 rack, optimizing control cabinet space.

Parameter Values

• Product Model: DO610 3BHT300009R1

• Brand: ABB

• Warranty: One Year

• Supply Voltage (Logic Side): 5 VDC (via S600 I/O bus)

• Field Supply Voltage: 24 VDC (Nominal), 20.4 – 30 VDC range

• Rated Current per Channel: 0.5 A

• Operating Temperature: 0°C to +60°C

• Storage Temperature: -40°C to +85°C

• Response Time: < 1 ms

• Output Type: 32 channels, Sinking, transistor-based

• Isolation: Opto-isolated in groups (typically 8 channels per group)

• Protection: Short-circuit and overload protection per channel

• Communication Interface: S600 I/O bus

Please contact Sunny [email protected] for the best price.

Application Scenarios

Batch Sequencing and Machine Automation: DO610 3BHT300009R1 Controlling pneumatic valves, tool changers, clamps, and status lights in automated assembly machines, packaging lines, and discrete manufacturing cells.

Process Plant Auxiliary Systems: Operating motorized damper actuators, lubrication system solenoids, local alarm horns, and pump sequencing relays in power generation or water treatment facilities.

Legacy System Support and Expansion: Serving as a direct replacement or capacity addition for existing ABB Advant OCS or MOD 300 systems, ensuring operational continuity in industries like metals, mining, and pulp & paper.
