Description
Summary
The Advance Optima process analyzer adopts a modular design, which helps ensure the long-term safety of your investment. The analyzer modules can be freely combined to form tailor-made solutions, and can be upgraded or expanded at any time, along with the addition of new features. It can be easily connected and operated centrally for remote modules.
The AO2000 series offers a variety of analysis modules. Up to four modules can be combined to form a tailor-made solution.
All the analyzers employ high-performance measurement technologies and simplified calibration methods, eliminating the need for using test gas cylinders.
Micro-oxygen analyzer
NDIR and UV photometer
In-situ laser module
Oxygen analyzer
Thermal conductivity analyzer
FID Analyzer
| Parameter | Value / Specification |
|---|---|
| Product Model: | AO2000 |
| Measurement Principle: | Configurable (TDLAS, NDIR, Paramagnetic, Electrochemical, Zirconia) |
| Number of Components: | 1 to 6 components per analyzer module |
| Typical Gases Measured: | O₂, CO, CO₂, NO, NO₂, SO₂, CH₄, NH₃, H₂O, HCl, HF |
| Range (Example for O₂): | 0-1% to 0-100% (multiple sub-ranges available) |
| Accuracy: | Typically ≤ ±1% of span or ≤ ±0.1% absolute for O₂ |
AO2020: 19-inch chassis, supporting controller, display/screen, keyboard, power supply and an analyzer module. An additional enclosure can support an external analyzer module.
AO2040: Wall-mounted, with an additional enclosure, capable of supporting an external analyzer module
Advance Optima has the following features that can bring you many benefits:
A central unit and various analyzer modules
– Supports universal control
– Supports the same connection technology
– Uses a unified system enclosure
All analyzers employ high-performance measurement technologies and simplified calibration, without the need to use test gas cylinders.
– Photometer
– In-situ laser analyzer
– Oxygen analyzer
– Micro-oxygen analyzer
– Thermal conductivity analyzer
– FID analyzer
Multi-analyzer system: Within a single system, there are up to four analyzer modules and up to six sample components.
Through air calibration or integrated calibration chambers, a large number of automatic calibrations can be achieved, without the need to use standard gas cylinders.
The self-check function indicates when maintenance is required.
The approved model for hazardous areas complies with ATEX and GOST-R, 2G, 3G categories and CSA Class I, Division 2.
In Zone 2, the “safety concept” for measuring flammable gases using 3G technology
Provide Ethernet TCP/IP interface, OPC server, PROFIBUS and Modbus interface
