1.Unboxing & Physical Snapshot (Dynamic List)
- Brand & Model: ABB System 800xA / Advant Controller CI854AK01 PROFIBUS-DP/V1 Communication Interface Module — 3BSE030220R9 (Includes CI854 module and TP854 baseplate configuration set)
- Physical Dimensions: Approx. 185 mm x 59 mm x 127.5 mm (Standard modular baseplate footprint)
- Estimated Shipping Weight: 0.59 kg (1.30 lbs) (Packaged within high-density antistatic foam and rigid double-walled corrugated casing)
- What’s in the Box: CI854 communication module unit, TP854 baseplate mounting interface, pluggable terminal blocks, and factory compliance certification tags. (Note: PROFIBUS optical links and field bus cables are sold separately).2.Product IntroductionIndustrial distributed control architectures rely on high-integrity communication interface modules to manage deterministic fieldbus data traffic between core controllers and remote PROFIBUS-DP slave devices. Plant instrumentation technicians mount this communication interface assembly securely onto DIN rail infrastructures inside system cabinets, utilizing redundant optical or electrical PROFIBUS channels to maintain continuous data exchange across demanding chemical, power, and manufacturing processes.
System reliability mandates utilizing authentic OEM ABB control hardware rather than unverified third-party circuit replacements. Deploying this exact CI854AK01 interface module ensures proper bus master synchronization, compliance with PROFIBUS-DP/V1 standards, and robust communication error-handling during critical plant operating cycles.
3.Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer / Product Family | ABB / System 800xA & Advant Controller AC 800M Architecture |
| Catalog Model / Part Number | CI854AK01 (Product ID: 3BSE030220R9 variant set) |
| Communication Protocol | PROFIBUS-DP / V1 Master interface |
| Transmission Speed | Up to 12 Mbit/s with automatic baud rate detection |
| Redundancy Support | Supports redundant master configuration for high availability |
| Power Requirements | Powered via baseplate bus rails (24 VDC nominal) |
| Operating Temperature | -20°C to +60°C industrial control room threshold |
| Enclosure Protection | IP20 modular baseplate assembly (DIN rail cabinet mounting) |
| Approximate Unit Weight | 0.59 kg (1.30 lbs) |
- Global Compliance & Industry CertificationsAuditors and plant safety engineers require comprehensive compliance documentation verifying that industrial network hardware satisfies international electrical safety and communication standards. This module aligns with major industrial benchmarks, carrying expected designations such as the CE Mark for European conformity, PROFIBUS Nutzerorganisation e.V. (PNO) certification for network interoperability, and rigorous Electromagnetic Compatibility (EMC) standards.
A proper PNO certification guarantees that the module’s protocol stack complies strictly with open fieldbus standards, preventing bus token drops and ensuring reliable data exchange across multi-vendor instrumentation loops. Verify specific lot certifications with OEM.
5.Long-Term Storage & Asset Preservation Guide (E-E-A-T Goldmine)
Communication processor modules sitting dormant in facility stockrooms require strict environmental discipline to prevent edge-connector pin oxidation and electrostatic discharge (ESD) degradation of sensitive integrated circuits. Keep the module hermetically sealed inside its original factory anti-static moisture-barrier bag until the exact minute of panel installation. Maintain stockroom climate controls with ambient temperatures stable between 15°C and 25°C and relative humidity strictly below 50 percent to protect multi-layer printed circuit boards from micro-corrosion. If this interface card remains unpowered in stock beyond three years, maintenance technicians should inspect the gold contact pins for tarnishing before deploying the unit to the field.
- Physical Installation PrerequisitesMount the TP854 baseplate securely onto a grounded DIN rail inside the controller cabinet, ensuring proper mechanical clearance before snapping the CI854 module firmly into place. Ensure the control cabinet maintains a low-impedance connection to the plant earth ground grid, and route PROFIBUS cable shields through dedicated grounding clamps to prevent electromagnetic common-mode interference.
- Buyer’s FAQ (Logistics & Compliance Focus)
- What Harmonized System (HS) tariff code governs international shipments of this communication module? Industrial network interface cards and modular data transmission apparatus typically fall under HS code 8517.62 (machines for reception, conversion and transmission of data), though customs brokers should verify local classifications.
- Does the module ship pre-loaded with application firmware and baseplate hardware? The suffix code indicates a complete bundle including the baseplate (TP854), but system integrators must configure node addresses and network parameters via the Control Builder Professional engineering tool during commissioning.
