SPHSS03 | -40 °C to +70 °C | hot standby synchronization module

Description

roduct Overview

The ABB SPHSS03 is a high-performance, hot standby synchronization module designed for ABB’s AC 800M High Integrity and AC 800M Safety controller families. Its primary function is to ensure flawless and deterministic synchronization between the processors in a redundant (1-out-of-2) controller pair, which is fundamental for achieving high availability and safety integrity levels (SIL). The module manages the precise exchange of data, clock signals, and system states between the primary and standby CPUs, enabling bumpless switchover in the event of a primary CPU failure with zero data loss..

Parameter Values

• Product Model: ABB SPHSS03
• Brand: ABB
• Warranty: One Year
• Input Voltage: 24 V DC
• Operating Temperature: 0 °C to +55 °C
• Storage Temperature: -40 °C to +70 °C
• Response Time: Synchronization cycle < 10 ms
• Protection Class: N/A (Mounted internally in controller rack)
• Accuracy Class: N/A
• Output Frequency: N/A
• Rated Current Consumption: 250 mA (typical)
• Communication Interface: Dedicated high-speed serial link (via internal backplane and external sync cable)
• Supported Protocols: ABB proprietary redundancy synchronization protocol
• Redundancy Switchover Time: < 50 ms
• Dimensions: 60 mm x 120 mm x 120 mm
•

Application Scenarios

• Safety Instrumented Systems (SIS): SPHSS03  Deployed in redundant AC 800M HI/Safety controllers to meet SIL 3 requirements for emergency shutdown (ESD) and fire & gas (F&G) systems.
• Critical Process Control: Ensuring continuous operation in high-availability applications within industries such as oil & gas production, chemical processing, and power generation.
• Infrastructure Protection: SPHSS03  Used in controller pairs managing critical infrastructure like compressor stations, pipeline SCADA, and turbine control, where reliability is paramount.
