1. Product Title
Delem DA-53T Touch-Screen Graphical CNC Control for Press Brakes
2. Product Overview
The DA-53T is a state-of-the-art, integrated CNC solution designed by Delem to streamline the operation of synchronized press brakes. Featuring a high-resolution 10.1″ wide-screen color TFT display with multi-touch technology, this controller offers a modern, intuitive interface for sheet metal bending.
The DA-53T solves the complexity of machine setup by providing a “Hot-Key” navigation system that allows the operator to switch directly between programming and production. It handles up to 4 axes (Y1, Y2, and two auxiliary axes) and features integrated crowning control. By utilizing graphical 2D programming, the DA-53T enables operators to visualize the bending sequence, reducing material waste and significantly shortening “art-to-part” production times in busy fabrication shops.
3. Technical Specifications
- Brand: Delem
- Model: DA-53T
- Warranty: One Year
- Condition: 100% New & Original
- Display: 10.1″ High-brightness color TFT
- Control: Industrial-grade Multi-touch Screen
- Memory: 1 GB Internal (Standard capacity for 1000s of programs)
- USB Interface: 2.0 (For flash drives, mouse, or keyboard)
- Communication: Ethernet (RJ45) and RS232
- Axis Support: Y1-Y2 (Cylinders) + 2 auxiliary axes (X, R, Z, or Crowning)
- Operating System: Embedded Windows-based real-time OS
- Input Power: 24V DC
4. Key Features & Benefits
- 2D Graphical Touch Programming: The DA-53T allows users to draw parts directly on the screen. The controller automatically calculates the optimal bend sequence and provides a visual simulation of the process.
- Integrated Crowning Control: Ensures consistent bending angles across the entire length of the workpiece by automatically adjusting the machine’s deflection compensation.
- Highly Flexible Tooling Library: Operators can store detailed data for punches and dies, allowing the <span style=”color: blue;”>DA-53T</span> to accurately calculate bend deductions and machine limits for various materials.
- Offline Programming Compatible: Supports Delem’s Profile-T software, allowing engineers to program parts in the office and transfer them to the <span style=”color: blue;”>DA-53T</span> via USB or network.
5. Application Scenarios
- Precision Metal Fabrication: Used in mid-range synchronized press brakes for producing cabinets, enclosures, and high-accuracy mechanical components.
- High-Mix, Low-Volume Production: Ideal for job shops that frequently change setups, as the DA-53T touch interface significantly reduces the time spent on manual axis positioning and tool calibration.
- Machine Retrofitting: A popular choice for upgrading older hydraulic press brakes to a modern graphical interface with network connectivity and automatic sequence calculation.
6. Frequently Asked Questions (FAQ)
- Q: What is the primary function of the <span style=”?
- A: It is a graphical CNC controller that manages the hydraulic cylinders (Y1-Y2) and backgauge axes of a press brake to ensure accurate and repeatable metal bending.
- Q: Does the DA-53T support 3D visualization?
- A: No, the DA-53T focuses on 2D graphical programming and visualization. For full 3D simulation, the Delem DA-60T series is typically recommended.
