1. Product Title
Kollmorgen AKM54H-ACCNC-00 – High-Torque Brushless Servo Motor
2. Product Overview
The AKM54H-ACCNC-00 is a high-performance permanent magnet synchronous servo motor from Kollmorgen’s AKM series, optimized for demanding industrial automation applications. This frame size 5 (AKM54) high-stack (H) configuration delivers exceptional torque density with low cogging, making it ideal for precise motion control in CNC machines, robotics, and packaging systems. The “ACCNC” designation indicates specific winding, connector, and flange options for continuous duty operation. Featuring advanced rotor design and multiple mounting variants, the <span style=”color: blue;”>Kollmorgen AKM54H-ACCNC-00</span> addresses challenges like high inertia loads and dynamic acceleration requirements while maintaining smooth operation across wide speed ranges.
3. Technical Specifications
- Brand: Kollmorgen
- Model:AKM54H-ACCNC-00
- Warranty: One Year
- Condition: 100% New & Original
- Frame Size: AKM5 (141 mm square flange)
- Stack Length: H (high torque)
- Continuous Stall Torque: 14.19 Nm (125 lb-in)
- Peak Torque: 37.5 Nm (331 lb-in)
- Rated Speed: 1000-2000 rpm (voltage dependent)
- Max Speed: 6000 rpm
- Pole Pairs: 5 (10 poles)
- Inertia: 11.9 kg·cm²
- Operating Voltage: 320-640 Vdc bus
- IP Rating: IP54 (IP65 shaft seal option)
- Weight: ~15 kg
4. Key Features & Benefits
- Ultra-High Torque Density: H-stack design provides maximum torque per frame size, enabling compact solutions for high-inertia applications.
- Low Cogging Torque: Patented rotor geometry ensures smooth motion at low speeds, critical for precision contouring and scanning.
- Flexible Mounting Options: “ACCNC” configuration supports multiple pilot diameters (95/110 mm) and shaft types (19/24 mm keyed/smooth).
- SpeedTec Connectors: Quick-release M23 connectors reduce wiring time and improve reliability under vibration.
5. Application Scenarios
- CNC Machining Centers: Drives high-inertia spindles and axes requiring precise positioning and rapid acceleration.
- Packaging Robotics: Powers articulated arms handling variable loads with smooth velocity profiling.
- Factory Automation: Controls servo axes in pick-and-place systems demanding high torque at low speeds.
6. Frequently Asked Questions (FAQ)
- Q: What is the primary function of the <span style=”color: blue;”>Kollmorgen AKM54H-ACCNC-00</span>?
A: High-performance servo motor for precise torque and speed control in industrial motion applications. - Q: Is <span style=”color: blue;”>Kollmorgen AKM54H-ACCNC-00</span> compatible with legacy systems?
A: Yes, works with Kollmorgen AKD/AKD2 drives and standard servo interfaces via SpeedTec connectors.
