GE IS420ESWBH3A – Ethernet IONet Switch Module
GE IS420ESWBH3A is an industrial Ethernet switch module integral to GE’s Mark VIe and Mark VIeS turbine control systems, providing high-speed IONet connectivity for real-time distributed control. This 16-port 10/100Base-TX copper switch facilitates deterministic communication between controllers, I/O packs, and HMIs using redundant ring topologies with sub-10μs latency. It addresses network reliability challenges in gas turbine environments by featuring conformal-coated electronics, dual power inputs, and electromagnetic interference immunity for continuous operation. The GE IS420ESWBH3A mounts on DIN rails with status LEDs, supporting unmanaged plug-and-play deployment in control enclosures.
Technical Specifications
- Brand: GE
- Model: IS420ESWBH3A
- Warranty: One Year
- Condition: 100% New & Original
- Series: Mark VIe / Mark VIeS
- Ports: 16 × 10/100Base-TX RJ45
- Data Rate: 100 Mbps full-duplex
- Power Supply: 18-32 VDC redundant
- Power Consumption: 12 W max
- Operating Temp: -40°C to +70°C
- Dimensions: 120 × 160 × 100 mm
- Weight: 0.8 kg
- Mounting: DIN rail
Key Features & Benefits
- Real-Time Determinism: IONet protocol optimization delivers microsecond-level synchronization essential for turbine sequencing and protection.
- Redundant Topology: Ring/daisy-chain configurations with auto-failover maintain communication during cable faults or switch failures.
- Industrial Hardening: Extended temperature range and EMI shielding ensure reliable networking in high-vibration turbine control rooms.
Application Scenarios
- Gas Turbine Networks: Interconnects VME controllers with remote I/O packs for synchronized fuel and speed control.
- Distributed HMI Systems: Links multiple operator stations and engineering workstations across power plant floors.
- Safety IONet Backbone: Provides fault-tolerant communication for Mark VIeS SIL-rated protection functions.
Frequently Asked Questions (FAQ)
- Q: What is the primary function of the GE IS420ESWBH3A?
- A: It serves as a 16-port Ethernet IONet switch for real-time turbine control networking in Mark VIe systems.
- Q: Is GE IS420ESWBH3A compatible with legacy systems?
- A: Yes, it supports standard 10/100Base-TX Ethernet and IONet protocol used in GE Speedtronic Mark VIe upgrades.
