GE IS230SNRTH2A – RTD Temperature Input Module
GE IS230SNRTH2A is a Resistance Temperature Detector (RTD) input module for GE’s Mark VIe turbine control systems, providing high-accuracy temperature measurement from field sensors in harsh industrial environments. This module supports multiple RTD types including Pt100, Pt1000, Ni120, and Cu10, with 3-wire compensation for lead resistance elimination across 16 channels. It addresses thermal monitoring challenges in turbines by delivering 16-bit resolution, fast scanning rates, and fault detection for open/shorted sensors, ensuring precise control inputs for protection and sequencing logic. The GE IS230SNRTH2A interfaces via Mark VIe Ethernet IONet with terminal boards like STRTDH2A, supporting redundant operation and hot-pluggable diagnostics in power generation cabinets.
Technical Specifications
- Brand: GE
- Model: IS230SNRTH2A
- Warranty: One Year
- Condition: 100% New & Original
- Series: Mark VIe
- Channels: 16 RTD inputs
- RTD Types: Pt100, Pt1000, Ni120, Cu10
- Wiring: 3-wire with compensation
- Resolution: 16-bit
- Accuracy: ±0.1°C
- Scan Rate: 100 ms per channel
- Operating Temp: -30°C to +65°C
- Power Supply: 28 VDC backplane
Key Features & Benefits
- Multi-RTD Compatibility: Software-configurable sensor types eliminate hardware changes, supporting diverse bearing and exhaust temperature monitoring.
- Lead Wire Compensation: Automatic 3-wire balancing corrects for cable resistance, maintaining measurement accuracy over long field runs.
- Fault Diagnostics: Detects open circuits, shorts, and out-of-range conditions with Ethernet reporting, enabling predictive maintenance.
Application Scenarios
- Gas Turbine Bearings: Monitors journal and thrust bearing temperatures for lube oil system protection in power plants.
- Steam Turbine Monitoring: Tracks steam chest and casing thermocouples in combined-cycle operations.
- Compressor Stations: Provides inlet/outlet temperature inputs for surge control in oil & gas compression trains.
Frequently Asked Questions (FAQ)
- Q: What is the primary function of the GE IS230SNRTH2A?
- A: It acquires RTD temperature signals with 3-wire compensation for Mark VIe turbine thermal protection systems.
- Q: Is GE IS230SNRTH2A compatible with legacy systems?
- A: Yes, it connects to standard STRTD terminal boards and Ethernet IONet, integrating with GE Mark VI controls.
