SUE3000 1VCR007346 G0028 | 45 Hz to 65 Hz | high-precision power

Description

Product Overview

The ABB SUE3000 1VCR007346 G0028 is a specialized, high-precision power measurement and conditioning module designed for the ABB S800 I/O system. It functions as a sophisticated transducer interface, converting signals from current and voltage transformers (CTs and VTs) connected to electrical power systems into standardized, accurate data for the Distributed Control System (DCS) or SCADA. This module is essential for comprehensive energy management, power quality analysis, and protective relay interfacing within industrial electrical networks. The ABB SUE3000 1VCR007346 G0028 calculates key electrical parameters—including true RMS values of voltage and current, active/reactive/apparent power, power factor, frequency, and energy—with high accuracy. Its robust design and isolation ensure safe and reliable operation in electrically harsh environments,

Parameter Values

• Product Model:SUE3000 1VCR007346 G0028
• Brand: ABB
• Warranty: One Year
• Input Voltage (Measuring): Up to 300 V AC line-to-neutral (via VT)
• Input Current (Measuring): 1A or 5A AC (via CT, configurable)
• Supply Voltage (Module): 24 V DC (via S800 I/O rack)
• Accuracy Class: 0.5% (for active power, per IEC 60688)
• Frequency Range: 45 Hz to 65 Hz
• Operating Temperature: -25 °C to +70 °C
• Communication Interface: ABB S800 I/O Link to controller
• Supported Protocols: Native S800 I/O protocol for System 800xA
• Measurement Update Rate: 200 ms (typical)
• Galvanic Isolation: 3 kV AC between field inputs and system side
• Power Consumption: 2.5 W (typical)
• Dimensions: Single S800 I/O module slot (121.5 mm x 130 mm)

Application Scenarios

• Substation & Switchgear Monitoring: SUE3000 1VCR007346 G0028  Integrating electrical parameter measurement into SCADA for medium-voltage substations, ring main units, and motor control centers (MCCs).
• Generator & Turbine Control: Providing precise power and frequency feedback for control and protection of gas, steam, or hydro turbine-generator sets.
• Plant Energy Management: Serving as the primary measurement point for energy sub-metering, cost allocation, and power consumption analysis across large industrial facilities like chemical plants, metals processing, and data centers.
