Description
Product Overview
The ABB INIIT03 is an advanced communication interface module from the Industrial IT (800xA) system family, designed to function as an Intelligent Interface to Turck’s fieldbus-independent, decentralized I/O system. This gateway module seamlessly bridges ABB’s high-level control environment with the versatile and robust Turck BL20/BL67 remote I/O stations. The ABB INIIT03 handles complex protocol conversion and data management, enabling the 800xA system to transparently access and control a wide array of digital and analog field devices connected to the remote Turck I/O blocks. This integration provides exceptional flexibility for distributed automation architectures, allowing for cost-effective and modular I/O deployment while maintaining the powerful engineering, visualization, and diagnostic capabilities of the ABB ecosystem.
Parameter Values
- Product Model: ABB INIIT03
- Brand: ABB
- Warranty: One Year
- Supply Voltage: 24 VDC (19.2 – 30 VDC)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Interface to Controller: 800xA system bus
- Interface to Field Network: Direct connection to Turck BL20/BL67 station via FTS (Field Termination System) interface
- Supported I/O Data: Up to 1024 bytes of input data and 1024 bytes of output data (module and configuration dependent)
- Transmission Rate: 1.5 Mbps (to Turck station)
- Number of Connected Stations: Typically 1 primary BL20/BL67 station with potential for local expansion
- Protocol Handling: Translates 800xA internal data protocol to/from Turck BL ident protocol
- Status Indication: LEDs for Power, Communication Status, System Error, and Station Status
- Configuration: Fully configured within ABB’s Control Builder for 800xA
- Power Consumption: 5 W (typical)
- Dimensions: Standard S800 I/O module form factor.
Application Scenarios
Distributed Process Control: Deploying remote I/O clusters close to field devices in large plant areas like tank farms, packaging halls, or material yards in chemical, food & beverage, or logistics facilities.
Machine Integration: Connecting OEM machinery equipped with a Turck BL I/O interface directly into a plant-wide ABB 800xA DCS, simplifying integration and providing uniform diagnostics.
Modular Skid & Package Plant Control: Serving as the primary I/O interface for skid-mounted process units that are pre-equipped with Turck remote I/O, allowing for “plug-and-produce” connectivity to the central DCS.
