ABB DIS0006 |  -25°C to +70°C | 6-position universal disconnect switch

Description

The ABB DIS0006 is an industrial-grade, 6-position universal disconnect switch designed for use in ABB’s System 800xA and AC 800M controller cabinets. It serves as a critical maintenance and safety component, providing a reliable means to physically isolate power or signal circuits for the controller, I/O modules, or associated field devices. Engineered for durability and clear operational status, the ABB DIS0006 features a robust rotary mechanism with a well-defined ON/OFF position and can be fitted with a locking handle to prevent unauthorized or accidental operation, complying with safety lockout/tagout (LOTO) procedures. Its universal contact design allows for flexible configuration as a voltage disconnector or as a maintained-contact selector switch

Parameter Values

• Product Model:DIS0006

• Brand: ABB

• Warranty: One Year

• Rated Insulation Voltage (Ui): 690 VAC

• Rated Operational Voltage (Ue): 400 VAC, 600 VAC (for specific uses)

• Rated Thermal Current (Ith): 20 A

• Utilization Category: AC-22A, AC-23A (switching of mixed resistive and inductive loads)

• Mechanical Life: > 30,000 cycles

• Electrical Life: > 10,000 cycles (at rated current)

• Protection Degree (IP): IP40 (front of panel), IP20 (behind panel)

• Operating Temperature: -25°C to +70°C

• Mounting: Panel-mounted, 30.5 mm cutout

• Contact Configuration: 3 poles (standard), convertible to 2 or 4 poles

• Auxiliary Contacts: Configurable options available (e.g., 1 NO + 1 NC)

• Handle Type: Rotary, lockable in OFF position (padlock provision)

Application Scenarios

Controller Cabinet Main Disconnect: DIS0006 Serving as the main manual disconnect switch for the 24 VDC or 115/230 VAC supply to an AC 800M controller rack and its associated I/O power distributors within an 800xA system cabinet.

Field Power Segment Isolation: Isolating power to specific groups of field instruments or final control elements (e.g., a bank of solenoid valves) to allow for safe maintenance on a subsection of the plant without shutting down the entire process.
