Description
Product Overview
The ABB 500BIM01 1MRB160024R0002 is a high‑performance 16‑channel digital input module from the ABB AC500 series. Designed for the AC500 PLC platform, it serves as the primary interface for monitoring binary signals from field devices such as sensors, switches, and safety interlocks.
This module ensures fast, noise‑immune signal acquisition with galvanic isolation and is engineered for reliable operation in demanding industrial environments. It is suitable for both new installations and system upgrades requiring high‑density, distributed digital inputs
Parameter Values
-
Product Model: ABB 500BIM01 1MRB160024R0002
-
Brand: ABB
-
Warranty: One Year
-
Module Type: 16‑Channel Digital Input Module
-
Input Channels: 16, isolated
-
Input Voltage Range: 24 V DC (20.4–28.8 V DC)
-
Input Current per Channel: Approx. 2–3 mA (at 24 V DC)
-
Supply Voltage: 24 V DC (sourced from AC500 backplane)
-
Current Consumption: ≤ 2.5 W
-
Isolation Voltage: 2.5 kV (channel‑to‑channel and channel‑to‑backplane)
-
Response Time: ≤ 5 ms (software‑configurable filtering)
-
Overvoltage Protection: ±30 V DC
-
Communication Interface: Via AC500 backplane (S2I bus), no direct fieldbus port
-
Supported Protocols: Managed by AC500 CPU (e.g., Modbus TCP, Profinet, Profibus DP)
-
Operating Temperature: -25°C to +70°C
-
Storage Temperature: -40°C to +85°C
-
Relative Humidity: 5% to 95% (non‑condensing)
-
Protection Class: IP20 (front panel / DIN‑rail mounting)
-
Mounting: DIN rail or panel mount on ABB AC500 rack
-
Dimensions (W × H × D): Approx. 36 mm × 175 mm × 110 mm
-
Weight: Approx. 0.3 kg
pplication Scenarios
-
Manufacturing Automation: Monitoring limit switches, emergency stops, and machine status on conveyor lines and robotic cells.
-
Process Industries: Collecting status signals from valves, pumps, and motor starters in oil & gas, chemical, and power plants.
-
Power Generation: Tracking turbine overspeed switches, generator breaker statuses, and auxiliary equipment interlocks.
-
Water & Wastewater Treatment: Interfacing with flow switches, level sensors, and pump start/stop signals for reliable process monitoring.
-
Building & Infrastructure: Integrating door contacts, occupancy sensors, and fire alarm status points into a centralized control system.
